Icom IC-PCR2500 [129/148] P25 mode setting

121

DIGITAL MODE OPERATION (IC-PCR2500 Main band only)

■ P25 mode setting

The IC-PCR2500 can receive in P25* mode.

*The optional UT-122 is required. Some versions already come with

the UT-122 installed.

q Click the zSettingx icon on the tool bar to call up the [Set-

ting] screen if it is not displayed.

w Click the zP25x tab to display the P25 setting.

e Click

q Click

w Set the setting

• [Setting] screen

Select the optional unit

power setting.

Check the check box to turn the RX ID indication ON,

when received.

Check the check box to turn the hexadecimal indication ON

zSettingx
