DRIVER INSTALLATION

iClick “ ” of the CD drive folder in “My Computer”.

• The CD drive folder name (e.g. “D”) is depending on a PC.

oSelect “Win” in the “Driver” folder, click [OK.]

!0Click [Next>].

!1When the driver is found, the following dialog is displayed.

Click [Next>] to start the installation.

Click

Select

Click
