Icom IC-PCR2500 [33/148] Application installation

APPLICATION INSTALLATION

■ Installation

qQuit all applications when Windows is running.

wInsert the CD into the CD drive.

eOpen the CD drive contents via “My computer” or “Win-

dows Explorer.”

• “Driver” and “Pcr1500_2500” folders are included.

rDouble click “Setup.exe” ﬁle in “Pcr1500_2500” folder.

• The “InstallShield

Wizard” starts preparing the installation.

tSelect the display language type from “English” or “Japan-

ese.” Click [Next>].

yAfter the preparation, the following dialog is displayed.

Click [Next>].

Click

Double click

_2500
