Icom IC-PCR2500 [13/148] Driver installation

DRIVER INSTALLATION

ySelect “Search for the best driver in these locations.” then

select “Include this location in the search,” click [Browse].

uClick “ ” of the CD drive folder in “My Computer.”

• The CD drive folder name (e.g. “D”) is depending on a PC.

iClick “ ” of the “Driver” folder in the CD drive folder, then

select “Win” folder.

Click [OK].

Click

Select

Click

Select
