Icom IC-PCR2500 [85/148] D clearing from the memory list

MEMORY CHANNELS

D Clearing from the memory list

q Click the zMemory Editx icon on the tool bar to call up the

[Memory Channel Editor] screen if it is not displayed.

w Click zYx(BANK) or zZx(BANK) to select a memory bank.

e Right click the cell of the unneeded memory channel to be

cleared, then click [Clear] from the displayed menu.

r Click [OK] in the displayed dialog box to clear the selected

memory channel contents.

[Memory Edit]

w Click

e Click

q Select a memory bank.

TUNING

MAIN SUB

IC-PCR1500 IC-PCR2500

• [Compo] screen

IC-PCR2500IC-PCR1500

• [Simple] screen

IC-PCR2500IC-PCR1500

zMCLx

MEMO

zYx/zZx

MEMO

zYx/zZx

BANK

zYx/zZx

BANK

zYx/zZx

zMCLx

BANK

zYx/zZx

MEMO

zYx/zZx

zM-CLx
