9. Turn arbor bolt (144) into saw spin-
dle (left-handed thread!) and tighten.
Hold outer blade collar (145) with
ring spanner to counter.
A
Danger!
− Do not extend arbor bolt tighten-
ing wrench.
− Do not tighten arbor bolt by hit-
ting on the wrench.
− After the arbor bolt has been
tightened, remove all tools used
during saw blade installation!
10. Fit table insert extrusion (147) flush
into the saw table.
11. Turn the countersunk screw (148)
counter-clockwise against the stop.
12. Install blade guard on the riving
knife.
10.2 Cleaning the saw blade's
height adjustment mech-
anism
1. Crank saw blade up to its uppermost
position.
2. Clean spindle with brush, vacuum,
or compressed air.
3. Apply a light coat of Care and Main-
tenance Spray.
4. Grease slide faces of the height
adjustment mechanism (149) and
crank the saw blade up and down
several times to distribute the
grease evenly on the slide faces.
10.3 Saw storage
A
Danger!
Store saw so that
− it cannot be started by unauthor-
ized persons, and
− nobody can get injured.
A
Caution!
Do not store saw unprotected
outdoors or in damp environment.
10.4 Maintenance
Before switching ON
Visual check if distance saw blade – riv-
ing knife is 3...8 mm.
Visual check of power cable and power
cable plug for damage; if necessary
have damaged parts replaced by a qual-
ified electrician.
After switching OFF
Check to see if the saw blade post-runs
for more than 10 seconds; if so, have the
electronic motorbrake replaced by a
qualified electrician.
Monthly (if used daily)
Remove saw dust and chips with vac-
uum or brush; apply light coat of oil to
guide elements:
− threaded rod of height adjustment;
− swivel segments.
Every 300 hours of operation
Check all screwed joints, retighten if
necessary.
A
Danger!
Repairs to electric tools must
be carried out by qualified electri-
cians only!
Electric tools in need of repair can be
sent to the service centre of your coun-
try. Refer to the spare parts list for the
address.
Please attach a description of the fault to
the electric tool.
• Lower saw blade fully.
• Dismount add-on parts (fence, slid-
ing carriage, table extension).
If possible use original carton for ship-
ping.
For special tasks the following accesso-
ries are available at your specialized
dealer – see back cover for illustrations:
A Sliding Carriage
For convenient guiding of long
stock.
B Table Side Extension, right-hand
tabel size 1000 mm x 600 mm;
with foldable support legs.
C Suction Adapter
To connect a shop vacuum to the
dust collection attachment.
D Care and Maintenance Spray
To remove resin residue and pre-
serve metal surfaces.
E Saw blade CV 315 x 1.8 x 30
56 multiple combination teeth
for solid wood and particle board.
F Saw blade CV 315 x 1.8 x 30
80 neutral multiple teeth
For especially smooth cuts in solid
wood and particle board.
G Saw blade TCT 315 x 2.8 x 30
48 universal alternate bevel teeth
For all woods and wood-derived
materials.
H Saw blade TCT 315 x 2.8/1.8 x 30
20 square teeth, combination bore
with locating holes
For rip and crosscuts in solid wood.
I Saw blade HW 315 x 3.0/2.0 x 30
24 alternate bevel teeth
General purpose blade for rip and
cross cuts, also in particle board.
J Roller Stand RS 420
K Roller Stand RS 420 W
L Roller Stand RS 420 G
The machine's packing can be 100%
recycled.
Worn out power tools and accessories
contain considerable amounts of valua-
ble raw and rubber materials, which can
be recycled.
These instructions are printed on paper
produced with elemental chlorine-free
bleaching process.
A
Danger!
Before carrying out any fault
service or maintenance work, always:
1. switch machine OFF;
2. unplug power cable;
3. wait for saw blade to come to
standstill.
Check that all safety devices are
operational again after each fault
service.
Motor does not run
Undervoltage relay tripped by power failure:
− switch on again.
No mains voltage:
− Check cables, plug, outlet and
mains fuse.
Motor overheated, e.g. by a blunt saw
blade or chip build-up in the chipcase:
− remove cause for overheating, wait
for a few minutes, then start saw
again.
Motor supply voltage too low:
− use a shorter extension cable or
extension cable with larger lead
cross section
(≥ 1.5 mm
2
).
147
148
149
11. Repairs
12. Transportation
13. Available accessories
14. Environmental Protection
15. Trouble Shooting
