31
ENGLISH
− Have power supply checked by a
qualified electrician.
Loss of cutting performance
Saw blade blunt (possibly tempering
marks on blade body or workpiece):
− replace saw blade (see chapter
"Care and maintenance").
Saw dust build-up
No dust collector or dust collector of
insufficient capacity connected (see
“Dust collector” in chapter “Operation”):
− Connect dust collector, or
− open sliding plate or
− increase suction capacity.
Height adjustment mechanism of saw
blade working stiff
Spindle of height adjustment mechanism
gummy:
− clean spindle and spray with Care
and Maintenance Spray (see chap-
ter "Care and maintenance").
Bevel tilt adjustment working stiff
Wing nut or retaining nut on on the oppo-
site side of the chip case tightened to
much:
− Slightly loosen wing nut or retaining
nut.
Motor carrier unit tilts independently
If the motor carrier unit tilts independ-
ently when setting the bevel tilt, the
retaining nut on the opposite side of the
chip case is not tightened enough:
− Adjust retaining nut as required.
16. Technical specifications
TKHS 315 M
2.5 WNB
TKHS 315 M
3.1 WNB
TKHS 315 M
3.4 DNB
TKHS 315 M
4.2 DNB
TKHS 315 M
2,5 WNB
Voltage 230 V / 1~50 Hz 230 V / 1~50 Hz 400 V / 3~50 Hz 400 V / 3~50 Hz 110 V / 1~50 Hz
Nominal current A 10,9 13,4 5,8 7,5 23
Fuse protection min. A 1 x 16 (time-lag) 1 x 16 (time-lag) 3 x 10 (time-lag) 3 x 16 (time-lag) –
Degree of protection IP 54 IP 54 IP 54 IP 54 IP 54
Motor speed min
-1
2750 2800 2700 2800 2750
Motor capacity input capacity P
1
power output P
2
kW
kW
2.5 kW S6
40%
1.72 kW S6
40%
3.1 kW S6
40%
2.2 kW S6
40%
3.4 kW S6
40%
2.5 kW S6
40%
4.2 kW S6
40%
3.0 kW S6
40%
2,5 kW S6
40%
1,6 kW S6
40%
Cutting speed saw blade approx. m/s 47 47 47 47 47
Saw blade diameter (outer) mm 315 315 315 315 315
Arbor bore mm 30 30 30 30 30
Depth of cut
with saw blade vertical
at 45° saw blade tilt
mm
mm
0...85
0...53
0...85
0...53
0...85
0...53
0...85
0...53
0 ... 85
0 ... 53
Dimensions
length saw table
width table
extension height
width saw table
length table extension
(saw table)
height (over all)
mm
mm
mm
mm
mm
mm
800
600
794
510
850
1000
800
600
794
510
850
1000
800
600
794
510
850
1000
800
600
794
510
850
1000
800
600
794
510
850
1000
Weight complete approx. kg 64 64 64 64 64
Sound power level
according to DIN 23746*
no-load
when sawing
Sound pressure level
according to DIN 31202*
no-load
when sawing
dB (A)
dB (A)
dB (A)
dB (A)
84,0
99,3
74,8
85,0
84,0
99,3
74,8
85,0
84,0
99,3
74,8
85,0
84,0
99,3
74,8
85,0
84,0
99,3
74,8
85,0
Ambient temperature range °C –10 … +40 –10 … +40 –10 … +40 –10 … +40 –10 … +40
Extension cable – min. lead cross section
Length of cable 10 m
Length of cable 25 m
Length of cable 50 m
mm
2
mm
2
mm
2
3 x 1.5
3 x 2.5
–
3 x 2.5
3 x 2.5
–
5 x 1.0
5 x 1.5
5 x 2.5
5 x 1.5
5 x 2.5
5 x 2.5
3 x 2,5
–
–
* The values stated here only indicate the loudness emitted by this machine. Whether the operator is required to wear hearing protec-
tion can not be determined here. This depends on how much noise reaches the ear of the operator. And this, among other things,
depends on the existing ambient conditions (such as other sources of noise near by). Even though it may not be explicitly required, it is
in your own interest to always wear hearing protection when operating this machine.
