SiBE12-728 Instruction
Operation Manual 181
2.2.2 Names of Parts
4
Names of parts
Indoor Unit
Opening the Front Panel
How to open the front panel: (page 26.)
CAUTION
Before opening the front panel, be sure to stop the operation and turn the breaker OFF.
Do not touch the metal parts on the inside of the indoor unit, as it may result in injury.
12
6
5
2
4
7
8
3
9
12
10
11
13
14
Air outlet selection switch
This setting blows air from upper outlet only.•
This setting automatically decides a blow
pattern depending on mode and conditions.
•
• The unit is shipped from the
factory with this setting.
• This setting is
recommended.
