Outdoor Unit SiBE12-728
284 Removal Procedure
1. Outdoor Unit
1.1 Removal of Outer Panels
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
External appearance
from front side.
1. Removing the suction
grille.
The hooks are secured in
the clearances of the heat
exchanger fins.
1
Undo the 2 hooks at the
bottom first.
(R6368)
Hooks
Rear side
(R6369)
Suction grille
(R6370)
