Printed Circuit Board Connector Wiring Diagram SiBE12-728
56 Printed Circuit Board Connector Wiring Diagram
1.6 Outdoor Units
Connectors PCB(1)(Main PCB)
PCB(2)(Service Monitor PCB)
Note: Other Designations
PCB(1)(Main PCB)
PCB(2)(Service Monitor PCB)
1) S10 Connector for terminal strip (indoor-outdoor transmission)
2) S15 Connector for COOL / HEAT mode lock
3) S20 Connector for electronic expansion valve coil A port (white)
4) S21 Connector for electronic expansion valve coil B port (red)
5) S22 Connector for electronic expansion valve coil C port (blue)
6) S23 Connector for electronic expansion valve coil D port (yellow)
7) S24 Connector for electronic expansion valve coil E port (green)
8) S40 Connector for overload protector
9) S51, S101 Connector for service monitor PCB
10) S70 Connector for fan motor
11) S80 Connector for four way valve coil
12) S90 Connector for thermistors
(outdoor air, heat exchanger, discharge pipe)
13) S92 Connector for gas pipe thermistor
14) S93 Connector for liquid pipe thermistor
15) AC1, AC2 Connector for terminal strip (power supply)
16) HR1, HR2 Connector for reactor
1) S52, S102 Connector for control PCB
1) FU1 Fuse (30A)
2) FU2, FU3 Fuse (3.15A)
3) V2, V3, V5, V9,
V100
Varistor
1) LED A Service monitor LED (green)
2) LED1 - LED5 Service monitor LED (red)
3) SW1 Forced operation ON/OFF switch
4) SW3 Wiring error check switch
5) SW4 Priority room setting switch
6) SW5 Night quiet mode setting switch
