SiBE12-728 Outdoor Unit
Removal Procedure 297
7
Undo the holder of the
thermistor.
The holder is secured in the
clearances of the heat
exchanger fins.
8
Remove the 3 fixing
screws on the partition
plate.
Step Procedure Points
(R6403)
Groove
(R6404)
(R6405)
