Outdoor Unit SiBE12-728
300 Removal Procedure
1.2 Removal of the Electrical Box
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
1 Remove the fixing
screw from the shut-off
valve mounting plate.
2 Remove the fixing
screw on the partition
plate.
3 Remove the 2 screws
to detach the earth
wires.
(
R6410
)
(R6411)
(R6412)
