Specifications SiBE12-728
16 Specifications
50Hz 230V
Model FTKS20CAVMB FTKS25CAVMB
Rated Capacity 2.0kW Class 2.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.7 (272) 7.7 (272)
M 5.9 (208) 5.9 (208)
L 4.2 (148) 4.2 (148)
SL 3.6 (127) 3.6 (127)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 258×834×325 258×834×325
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/32/25/22
Sound Power H dBA 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain
mm
φ
18.0
φ
18.0
Drawing No. 3D050947 3D050949
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model FTKS35CAVMB FTKS50FV1B
Rated Capacity 3.5kW Class 5.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.7 (272) 14.7 (519)
M 6.0 (212) 12.4 (438)
L 4.4 (155) 10.3 (364)
SL 3.8 (134) 9.5 (335)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.15
Power Consumption (Rated) W 40 34
Power Factor % 96.6 98.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 290×1,050×238
Packaged Dimensions (H×W×D) mm 258×834×325 337×1,147×366
Weight kg 7.5 12
Gross Weight kg 11 17
Operation
Sound
H/M/L/SL dBA 39/33/26/23 43/39/34/31
Sound Power H dBA 57 59
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas
mm
φ
9.5
φ
12.7
Drain
mm
φ
18.0
φ
18.0
Drawing No. 3D050951 3D056016
