SiBE12-728 Specifications
Specifications 23
1.2 Outdoor Units - Cooling Only
50Hz 230V
Note:
1. The data are based on the conditions shown in the table below.
Model 5MKS90E7V3B
Cooling Capacity
kW
—
Power Consumption
W
—
Running Current
A
—
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63BXD
Motor Output W 1,920
Refrigerant Oil
Model FVC50K
Charge L 0.75
Refrigerant
Type R-410A
Charge kg 2.95
Air Flow Rates
m³/min
H 54.5
L46
cfm
H 1,924
L 1,624
Fan
Type Propeller
Motor Output W 66
Running Current A H: 0.97 / L: 0.69
Power Consumption W H: 86 / L: 55
Starting Current A 11.4
Dimensions (H×W×D) mm 770×900×320
Packaged Dimensions (H×W×D) mm 900×925×390
Weight kg 69
Gross Weight kg 78
Operation Sound dBA 48
Sound Power dBA 62
Piping Connection
Liquid mm
φ
6.4
×
5
Gas mm
φ
9.5
×
2,
φ
12.7
×
1,
φ
15.9
×
2
Drain mm
φ
25.0
Heat Insulation Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 75 (for Total of Each Room)
m 25 (for One Room)
Amount of Additional Charge g/m 20 (65m or more)
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units)
Drawing No. 3D052440#1B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
7.5m
