Outdoor Unit SiBE12-728
294 Removal Procedure
11
Remove the front panel
(1).
The back is a little
complicated in shape. Be
sure to detach carefully.
6. Removing the rear panel
1
Remove the fixing
screw on the partition
plate.
Step Procedure Points
(R6396)
(R6397)
