SiBE12-728 Specifications
Specifications 17
50Hz 230V
Model FTKS60FV1B FTKS71FV1B
Rated Capacity 6.0kW Class 7.1kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 16.2 (572) 17.4 (614)
M 13.6 (480) 14.6 (516)
L 11.4 (403) 11.6 (410)
SL 10.2 (360) 10.6 (374)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.20
Power Consumption (Rated) W 40 45
Power Factor % 96.6 97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 45/41/36/33 46/42/37/34
Sound Power H dBA 61 62
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D056017 3D056018
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
