SiBE12-728 Outdoor Unit
Removal Procedure 293
9
Remove the screw at
bottom of the back side.
10
The front panel (1) is
provided with a hook on
its front. Lift the front
panel off position to
remove it.
Step Procedure Points
(R6394)
Hook
(R6395)
