Outdoor Unit SiBE12-728
292 Removal Procedure
6
Remove the 2 fixing
screws on the partition
plate.
7
Remove the screw at
bottom left of the front.
8
Remove the screw at
bottom of the left side.
Step Procedure Points
(R6391)
(R6392)
(R6393)
