Outdoor Unit SiBE12-728
314 Removal Procedure
2
Remove the spring from
the heat exchanger
thermistor.
Be careful no to lose the
spring.
3
Slightly open the sound
blanket.
4
Remove the sound
blanket (top upper).
Step Procedure Points
(R6452)
SpringSpring
(R6453)
(R6454)
