SiBE12-728 Outdoor Unit
Removal Procedure 309
4. Removing the servicing
cover off the terminal
block assembly.
1 Remove the screw.
2 Lift the hook to detach.
3 Open the cover toward
yourself.
Step Procedure Points
(R6438)
(R6439)
(R6440)
