Aten PG95330 [102/136] Cascade

eco PDU PG Series User Manual

108

Cascade

Cascade page displays the eco PDU's status as illustrated below:

Item Description

Supported Model

PG95

Series

PG96

Series

PG98

Series

State State shows which mode this eco

PDU is in:



Standalone:

The unit is without being

connected to other PG series

PDUs.



Primary:

The unit is the master unit among

the cascaded devices.



Secondary:

The unit is the slave unit among

the cascaded devices.

  

ID ID indicates the order of the unit

among the cascaded device.

  
