eco PDU PG Series User Manual

3. Provide a valid Username and Password (set by the eco PDU

administrator).

4. Select your preferred Language from the drop-down menu.

5. Click Login to bring up the browser main page.

The eco PDU Main Page

After you have successfully logged in, the eco PDU main page comes up with

the Energy Connections page displayed:

Note: The screen depicts an administrator’s page. Depending on the type of

user logged in and its permissions, and your PG model, not all of these

elements may appear.
