Chapter 1. Introduction
23
Rotatable LCD Screen—capable of 180-degree rotation, delivering
flexible in-rack installation
Secure locking enhancement prevents power cords from becoming
unplugged due to vibration or human error
Supports ATEN’s eco DC (Energy & DCIM Management Web GUI) for
monitoring power distribution, energy, and environmental data from PDUs
and connected devices
Note: 1. To be included in a future firmware release.
2. To be included in a future firmware release.
3. Please contact the local sales representative for further information on
the environmental sensor.
Proactive Overload Protection (POP)
The PG96 and PG98 series models feature ATEN's exclusive Proactive
Overload Protection (POP) technology. Effective on all non-critical outlets,
this added safety feature automatically powers off outlets when a current
overload occurs.
POP mode is engaged, powering off the outlets, when the current exceeds the
maximum threshold value set. The LED display shows POP and a beeper
sounds. Press any button for two seconds to clear POP mode and power the
outlets back on.
Note: PG95 series doesn't support POP function.
