Chapter 1

Introduction

Overview

ATEN PG 3-Phase Intelligent PDU lineup contains PG95 metered models,

PG96 switched models, and PG98 outlet-meteredswitched models. Each PG

PDU comes with 6 x IEC 60320 C19 and 24 x IEC 60320 C13 outlets in a 0U

rack enclosure. With an ARM Cortex-A8 processor, the PG series delivers

flexible control methods through its LAN / COM / USB / environment sensor

ports as well as powers up all connected equipment in less than 10 seconds

once plugged in. For cost-saving and space-efficient setup purposes, the PG

PDUs can be cascaded to connect up to 64 PDU units. As a result, these PDUs

accommodate the increasing demand for power to high-density IT devices in

server rooms and data centers.

In terms of hardware design, the PG96 and PG98 series PDUs have built-in

energy-saving relays, a subtype of electromagnetic switch, to help operators

control large amounts of current flow, which results in lower energy

consumption compared to non-relay models incapable of energy saving.

Other highlights include the circuit breaker preinstalled onto the PG95330 /

PG96330 / PG98330 models that support 30A / 32A current flow, which

automatically switches off electricity supply to protect devices from overload

or damage. With five colors (yellow, red, purple, blue, and green) of LCD

console panel stickers available for users to choose from, differentiating

between power feed settings and speeding up troubleshooting are made easier.

Plus, the LCD console panel is hot-swappable and can be removed, replaced,

or repaired without powering down a mission-critical connected load.

Ideal for enterprise servers, network closets, and data centers, the PG series is

an intelligent power distribution and management solution that supports high-

density IT applications while minimizing the overall cost.
