Aten PG95330 [57/136] Chapter 7

Chapter 7

Log

The eco PDU keeps a record of all transactions that take place on its

installation, and stores up to 1024 events at a any given time. The System Log

page provides a powerful array of filters and functions that allow you to view

and export the log file data, as well as be informed by SNMP Trap / Syslog /

SMTP of specified events as they occur.
