Chapter 10. LCD Menu
101
Press SELECT button, and you will enter the page which shows the unbalanced
current of L1, L2, and L3 by percentage whose range is from 0% to 200%.
Press SELECT button again to separately check the status of L1, L2, and L3.
Press ENTER button for 2 seconds to enter the main menu page. See the
following sections for more information and operation about the functions
listed on the main menu.
Device
- unbalanced current
50%
L1 50%
L2 50%
L3 50%
Device
- unbalanced current
50%
L1 50%
L2 50%
L3 50%
