![Aten PG95330 [30/136] Bridge](/views2/1978006/page30/bg1e.png)
eco PDU PG Series User Manual
36
Bridge
To bridge multiple ATEN eco PDUs, all the eco PDUs should be installed and
connected on the same location, and the units should be with the same IP
address.
Note: If you'd like to set the master unit and the slave units, please disable the
function “Bridge” for your master unit through the unit's LCD menu
while all the other slave units' Bridge function are enabled. See Bridge,
page 107 for details.
To save IP from switch router and use Intranet to share LAN, please
connect your eco PDUs as the steps below:
1. Connect the first (master) unit's LAN 1 port to switch router.
2. Connect the first unit's LAN 2 port to LAN 1 port of the second unit (slave
unit).
3. Connect the LAN 1 port and LAN 2 port of the second unit.
4. Connect the second unit's LAN 2 port to LAN 1 port of the next unit (slave
unit).
5. Repeat the procedures similar to step 3 and step 4 to connect other slave
units to complete your installation.
To use one set of IP address from switch router, connect your eco PDUs as
the steps below:
1. Connect the first (master) unit's LAN 1 port to switch router.
2. Connect the first unit's LAN 1 port to its LAN 2 port.
3. Connect the first unit's LAN 2 port to LAN 1 port of the second unit (slave
unit).
4. Connect the LAN 1 port and LAN 2 port of the second unit.
5. Connect the second unit's LAN 2 port to LAN 1 port of the next unit (slave
unit).
6. Repeat the procedures similar to step 4 and step 5 to connect other slave
units to complete your installation.
Note: The last slave unit cannot be connected to any switch router.
