Appendix
139
PG98330B / PG98330B2 / PG98330G
Compliance
EMC
Verification
FCC CE, EMC
Safety
Verification
UL, PSE CE
Warranty 3 Years
Function PG98330B PG98330B2 PG98330G
Electrical
Nominal Input
Voltage 208V 3PH (Delta)
400/230V 3PH (Star)
Maximum Input
Current
30A (Max);
24A (UL de-rated)
32A (Max)
Input
Frequency
50 - 60 Hz
Input
Connection
NEMA L21-30P NEMA L15-30P IEC 60309 32A Red 3P+N+E
Input Power
10808VA (Max),
8464VA (UL de-rated)
22170VA (Max)
Outlet Type
(6) IEC 60320 C19,
(24) IEC 60320 C13
Nominal
Output Voltage
208 Vac 230 Vac
Maximum
Output
Current (Outlet)
C13: 15A (Max),
12A (UL de-rated)
C19: 20A (Max),
16A (UL de-rated)
C13:10A (Max),
C19:16A (Max)
Breakers 3 x UL489(2P)-20A 6 x UL489(1P)-16A
Metering Outlet level current, voltage, PF and KWh Monitoring
Outlet
Switching
Yes
Environment
Sensor Ports
Yes
