eco PDU PG Series User Manual
122
Reboot PDU Device
The Reboot PDU Device command allows you to reboot the eco PDU.
The formula for Reboot PDU Device commands is as follows:
Command + [Enter]
1. For example, if you want to reboot the eco PDU, type the following:
reboot [Enter]
The following tables show the possible values for the Read Environmental
Value commands:
The following table lists the available Reboot PDU Device command:
Reset All PDU Config to Default Value
The Reset All PDU Config to Default command allows you to reset the eco
PDU to the default factory settings.
The formula for Reset All PDU Config to Default Value commands is as
follows:
Command + [Enter]
1. For example, if you want to reset the eco PDU, type the following:
clearallsetting [Enter]
The following tables show the possible values for the Reset All PDU Config to
Default Value commands:
Command Description
reboot Reboot PDU device command
Command Enter Description
reboot [Enter]
Reboots the
eco PDU
.
Command Description
clearallsetting Reset all PDU configuration to
default value command
