Chapter 4. Logging In
47
Page Components
The web page screen components are described in the table below:
The Energy page has two tabs: Connections and Configuration, as described in
the chapters that follow.
No. Item Description
1 Tab Bar The tab bar contains the eco PDU’s main operation
categories. The items that appear in the tab bar are
determined by the user’s type, and the setting
permissions that were selected when the user’s
account was created.
2 Menu Bar The menu bar contains operational subcategories
within the item selected on the tab bar. The items
that appear in the menu bar are determined by the
user’s type, and the setting permissions that were
selected when the user’s account was created.
3 Sidebar The sidebar provides a tree view listing of outlets
that relate to the various tab bar and menu bar
selections.
4 Help Connects to the online help section on the ATEN
website for the device’s configuration and operation.
5 Logout Click this button to log out of your eco PDU session.
6 Interactive Display Panel This is your main work area. The screens that
appear reflect your menu choices and the sidebar
node selection.
