Aten PG95330 [105/136] To back up or restore the configurations of the eco pdu or to perform firmware upgrade please insert a usb drive to usb type a port in advanced see status panel page 26 for deta...
![Aten PG95330 [105/136] To back up or restore the configurations of the eco pdu or to perform firmware upgrade please insert a usb drive to usb type a port in advanced see status panel page 26 for deta...](/views2/1978006/page105/bg69.png)
Chapter 10. LCD Menu
111
PDU
To back up or restore the configurations of the eco PDU, or to perform
firmware upgrade, please insert a USB drive to USB Type-A port in advanced.
See Status Panel, page 26 for details.
Item Description
Supported Model
PG95
Series
PG96
Series
PG98
Series
Backup Back up the configurations of your eco
PDU and save it to the connected
USB drive.
Restore Import the file saved on the connected
USB drive to restore the
configurations of your eco PDU.
Upgrade
Firmware
Use the file saved on the connected
USB drive to upgrade the firmware of
the eco PDU.
