Aten PG95330 [25/136] Pdu placement

Chapter 2. Hardware Setup

PDU Placement

For safety reasons, the eco PDU shall NOT be installed with the power sockets

facing up or down, and thus should only be installed with the power sockets

facing out from a vertical position, as shown below:

Note: The eco PDU models shown in the diagrams are for rack mount

reference purposes only.

Right.

Wrong

Floor
