eco PDU PG Series User Manual
138
PG98230B / PG98230B2 / PG98230G
Function PG98230B PG98230B2 PG98230G
Electrical
Nominal Input
Voltage 208V 3PH (Delta)
400/230V 3PH (Star)
Maximum Input
Current
20A (Max);
16A (UL de-rated)
16A (Max)
Input
Frequency
50 - 60 Hz
Input
Connection
NEMA L21-20P NEMA L15-20P IEC 60309 16/20A Red
3P+N+PE
Input Power
7205VA (Max),
5764VA (UL de-rated)
11084VA (Max)
Outlet Type
(6) IEC 60320 C19,
(24) IEC 60320 C13
Nominal
Output Voltage
208 Vac 230 Vac
Maximum
Output
Current (Outlet)
C13: 15A (Max),
12A (UL de-rated)
C19: 20A (Max),
16A (UL de-rated)
C13:10A (Max),
C19:16A (Max)
Breakers N/A
Metering Outlet level current, voltage, PF and KWh Monitoring
Outlet
Switching
Yes
Environment
Sensor Ports
Yes
Metering
Accuracy
1%
Physical Properties
Dimensions
(L x W x H)
179.00 x 5.60 x 6.80 cm
(70.47 x 2.2 x 2.68 in.)
Weight 7.36 kg
(16.21 lb)
Power Cord
Length
3 m
Environmental
Temperature
(Operating /
Storage)
0 – 60 °C / -20 – 60 °C
Humidity
(Operating &
Storage)
0 – 80% RH, non-condensing
