Chapter 1
Introduction
Overview
Engineered to be an intelligent power distribution solution, the IP Control Box
ships with 4 power outlets in an IEC or NEMA socket configuration. It
provides secure, centralized, intelligent, and remote power management of
data center IT equipment to minimize the operating cost.
The IP Control Box features remote power control function, allowing you to
control devices attached to the PDU at the PDU device level from practically
any location via a TCP/IP connection. The power sequence design eliminates
the risks for a power inrush to guarantee reliable operation and protects the
overall system health. With the support for eco DC software, it provides an
easy method for managing multiple devices, offering an intuitive and user-
friendly Graphical User Interface that allows you to configure a PDU device
and reboot the device in case any equipment lock-up occurs. The
administrators can switch on/off or set a delay time for each power outlet or
individual power outlets group whenever, wherever.
The IP Control Box boasts a slim, compact form factor and supports desk
mount as well as rack mount, ensuring easy installation in confined spaces. It
is a smart power control box tailored for hospitality or retail applications, such
as digital signages and video walls, for edge computing devices, including
routers, servers and cameras, or for any data center environments where there
is no need to keep the servers powered on at all times.
