Chapter 4. Browser Operation
23
When you have finished making your configuration settings, click Save.
Auto Ping Method Auto Ping Method defines the mechanism which the IP Control
Box uses to ping a device and to reboot the outlet. To enable
this setting, check the Enable checkbox, or check the Disable
checkbox to disable.
Reboot Outlet
Enable this setting to reboot the outlet when the IP Control
Box fails to ping the device for the specified number of
times, as set in the Cont. Fail Reset field.
Ping Interval
Enter the number of seconds to elapse between each auto-
ping that is sent to test the network device.
Cont. Fail Reset
Enter the maximum number of times that the IP Control Box
pings the specified device after an initial failure.
Retries
Enter the maximum number of times that the IP Control Box
reboots the specified device after the consecutive pings, as
specified in the Cont. Fail Reset field.
Power-on Delay
Enter the duration to wait before the outlet is powered on
during a reboot.
IP Address
Enter the IP address of the device you want to ping.
Control/Display Description
