IP Control Box User Manual
60
The following table lists the available Read Environmental Value commands:
Note: 1. Each command string can be separated with a space.
2. The Option command string can be skipped and format will be used
by default.
Close Telnet Session
The Close Telnet Session command allows you to disconnect the telnet session
from the IP Control Box.
The formula for the Close Telnet Session command is as follows:
Command + [Enter]
1. For example, if you want to disconnect the telnet session, type the
following:
quit [Enter]
The following table shows the value for the Close Telnet Session command:
The following table lists the Close Telnet Session command:
Command Sensor Option Enter Description
read sensor oXX simple
format
[Enter] Read the environmental sensor value
on the selected power outlet with
environmental sensor installed. Outlet
XX with option simple or format. XX:
Outlet number (01 ~ 04).
Command Description
quit Close telnet session command
Command Enter Description
quit [Enter] Disconnects telnet session with PE4104G.
