![Aten PE4104G [67/84] Switch outlet status](/views2/1978081/page67/bg43.png)
Chapter 5. Telnet Commands
57
Switch Outlet Status
The Switch Outlet Status command allows you to change the power status of
an outlet on the IP Control Box.
The formula for Switch Outlet Status commands is as follows:
Command + Outlet + Number + Option + Control + [Enter]
1. For example, if you want to switch off outlet 04 immediately, type the
following:
sw o04 imme off [Enter]
2. For example, if you want to switch on outlet 01 with the time delay set for
the outlet, type the following:
sw o01 delay on [Enter]
3. For example, if you want to reboot outlet 03, type the following:
sw o03 reboot [Enter]
The following tables show the possible values for the Switch Outlet Status
commands:
Command Description
sw Switch outlet status command
Outlet Description
o Outlet command
xx PDU Outlet number
xx: Outlet on PDU (01 ~ 04)
Example: o02
Option Description
imme Switch outlet status
immediately
delay Switch outlet status with pre-
configured delay time
Control Description
on Switch outlet on
off Switch outlet off
reboot Switch outlet off and then
switch outlet on
