Aten PE4104G [65/84] Commands

Chapter 5. Telnet Commands

Commands

Use the Telnet commands to view and configure the IP Control Box as

described in each section. The text-based command line provides some of the

same functions found under the Energy tab of the IP Control Box’s web-based

GUI. Commands to view and configure the IP Control Box are provide in the

following sections. You can reference information provided in the user manual

for the functions as you use the commands.

Verification

After sending an incorrect command, a verification message appears at the end

of the command line.

 Invalid command or exceed max command length - the command has

the wrong format and/or values. Try typing in the command string again

using the correct format and/or values.
