Chapter 4. Browser Operation
39
Working Mode
If Enable Telnet Server is checked, the PDU is accessible via a Telnet
sessions using the Telnet username and password (see Telnet, page 25)
If Enable Modbus is checked, the PDU is accessible and the measurements
of the PDU such as current, voltage, power, temperature, humidity, and
pressure can be read via the Modbus communications protocol.
If Enable SSH is checked, the PDU is accessible and the measurements of
the PDU such as current, voltage, power, temperature, humidity, and
pressure can be read via the SSH cryptographic network protocol.
TLS Support
If TLS Support is checked, the PDU is accessible on older computers or
older web browsers that support TLS1.0 or TLS1.1 data encryptioin.
IPInstaller Setting
If Disable is checked, the IP address of the IP Control Box cannot be
found by the IP Installer software.
If Readonly is checked, the IP address of the IP Control Box can be found
but not configurable by the IP Installer software.
If Read-write is checked, the IP address of the IP Control Box can be
found and configurable by the IP Installer software.
Session Timeout
If Enable Web Session Timeout in is checked, a user's web session will
logout due to inactivity after the number of Minute(s) entered (1–5) is
surpassed.
Account Policy
The Account Policy section governs policies in regard to usernames and
passwords.
