Chapter 5. Telnet Commands
59
Read Environmental Value
The Read Environmental Value command allows you to view measurements
from the IP Control Box’s environmental sensors.
The formula for Read Environmental Value commands is as follows:
Command + Outlet + Number + Option + [Enter]
1. For example, if you want to read environmental sensor 02 with a simple
return string, type the following:
read sensor o02 simple [Enter]
2. For example, if you want to read environmental sensor 01 with a format
return sting, type the following:
read sensor o01 format [Enter]
The following tables show the possible values for the Read Environmental
Value commands:
Command Description
read sensor Read environmental sensor
value command.
Outlet Description
o Outlet with environmental
sensor installed command
xx PDU Outlet number with
environmental sensor installed
xx: Outlet on PDU (01 ~ 04)
Example: o02
Option Description
simple Return simple string of the
environmental sensor value on
the selected power outlet with
environmental sensor installed.
format Return format string of the
environmental sensor value on
the selected power outlet with
environmental sensor installed.
