Aten PE4104G [5/84] Product information

IP Control Box User Manual

Product Information

For information about all ATEN products and how they can help you connect

without limits, visit ATEN on the Web or contact an ATEN Authorized

Reseller. Visit ATEN on the Web for a list of locations and telephone numbers:

Package Contents

Check to make sure that all the components are in working order. If you

encounter any problem, please contact your dealer.

 1 IP Control Box

 1 standard rack mount kit

 1 power cord (applicable to PE4104G only)

 4 foot pads

 1 user instructions

International http://www.aten.com

North America http://www.aten-usa.com
