Chapter 5. Telnet Commands
61
Reboot PDU Device
The Reboot PDU Device command allows you to reboot the IP Control Box.
The formula for Reboot PDU Device commands is as follows:
Command + [Enter]
1. For example, if you want to reboot the IP Control Box, type the following:
reboot [Enter]
The following tables show the possible values for the Read Environmental
Value commands:
The following table lists the available Reboot PDU Device command:
Reset All PDU Config to Default Value
The Reset All PDU Config to Default command allows you to reset the IP
Control Box to the default factory settings.
The formula for Reset All PDU Config to Default Value commands is as
follows:
Command + [Enter]
1. For example, if you want to reset the IP Control Box, type the following:
clearallsetting [Enter]
The following tables show the possible values for the Reset All PDU Config to
Default Value commands:
Command Description
reboot Reboot PDU device command
Command Enter Description
reboot [Enter]
Reboots the
IP Control Box
.
Command Description
clearallsetting Reset all PDU configuration to
default value command
