IP Control Box User Manual
72
PE4104G
Outlet 4 x IEC C13
Inlet IEC C14
LAN Port 1 x RJ-45 Female with LEDs (Silver / LED:
Orange / Green)
10/100M
LED Outlet 4 x Green
Power 1 x Orange
Sensor 1 x Orange
Buttons Reset 1 x Semi-recessed Pushbutton
Select 4 x Select Pushbuttons
Sensor Port 1 x RJ11
Door Sensor 1 x Phoenix Connector (+12/D+/D-/G)
Electrical
Nominal Input Voltage 100–240 V
Maximum Input Current 10A Max
Input Frequency 50–60Hz
Input Connection IEC C14
Input Power 2400VA Max
Outlet Type (4) IEC C13
Normal Output Voltage 100–240 V
Maximum Output Current (Outlet) 10A Max
Maximum Output Current (Bank) 10A Max
Maximum Output Current (Total) 10A Max
Circuit Breakers Yes (UL1077)
Metering No
Outlet Switching Yes
Power Consumption AC110V:3.1W:20BTU
AC220V:3.5W:22BTU
Physical Properties
Housing Metal
Dimensions (W x L x H) 11.50 X 20.00 x 4.40 cm
Weight 0.90 kg
Power Cord Length 3 m
