Aten PE4104G [13/84] Requirements

Chapter 1. Introduction

Requirements

 Browsers accessing the IP Control Boxunit must support 2048 and 4096

bit encryption.

 For cold booting of attached computers, the computer’s BIOS must

support wake on LAN or System after AC Back.

 For Safe Shutdown:

 The computer must be running Windows (Windows 2000 or higher) or

Linux.

 The Safe Shutdown program (available by download from our

website), must be installed and running on the computer.
