IP Control Box User Manual
56
Read
Power
Outlet Status
The Read Power Outlet Status command allows you to view the power status
of an outlet on the IP Control Box.
The formula for Read Outlet Status commands is as follows:
Command + Outlet + Number + Option + [Enter]
1. For example, if you want to read the status of outlet 01 with a simple
return string, type the following:
read status o01 simple [Enter]
2. For example, if you want to read the status of outlet 12 with a format
return string, type the following:
read status o12 format [Enter]
The following tables show the possible values for the Read Outlet Status
commands:
The following table lists the available Read Outlet Status commands:
Note: 1. Each command string can be separated with a space.
2. The Option command string can be skipped and format will be used
by default.
Command Description
read status Read status command
Outlet Description
o Outlet command
xx PDU Outlet number
xx: Outlet on PDU (01 ~ 04)
Example: o02
Option Description
simple Return simple string of the
selected power outlet status
format Return format string of the
selected power outlet status
Command Outlet Option Enter Description
read status oXX simple [Enter] Read the status of outlet XX with a simple
return string. XX: Outlet number (01 ~ 04)
read status oXX format [Enter] Read the status of outlet XX with a format
return string. XX: Outlet number (01 ~ 04)
