IP Control Box User Manual
70
Specifications
PE4104AJ
Outlet 4 x NEMA 5 - 15P
Inlet SR
LAN Port 1 x RJ-45 Female with LEDs (Silver / LED:
Orange / Green)
10/100M
LED Outlet 4 x Green
Power 1 x Orange
Sensor 1 x Orange
Buttons Reset 1 x Semi-recessed Pushbutton
Select 4 x Select Pushbuttons
Sensor Port 1 x RJ11
Door Sensor 1 x Phoenix Connector (+12/D+/D-/G)
Electrical
Nominal Input Voltage 100–120 V
Maximum Input Current 15A Max
Input Frequency 50–60Hz
Input Connection NEMA 5 - 15P
Input Power 1800VA Max
Outlet Type (4) NEMA 5 - 15R
Normal Output Voltage 100–120 V
Maximum Output Current (Outlet) 15A Max
Maximum Output Current (Bank) 15A Max
Maximum Output Current (Total) 15A Max
Circuit Breakers Yes
Metering No
Outlet Switching Yes
Power Consumption AC110V:3.1W:20BTU
Physical Properties
Housing Metal
Dimensions (W x L x H) 11.50 X 20.00 x 4.40 cm
Weight 0.9 kg
