Chapter 4. Browser Operation
37
As an alternative to specifying the date and time by entering them into the
date and time fields, you can click to put a check in the Sync with PC
checkbox, in which case the eco PDU will take its date and time settings
from the locally connected PC.
Network Time
To have the time automatically synchronized to a network time server, do
the following:
1. Check the Enable auto adjustment checkbox.
2. Drop down the time server list to select your preferred time server
– or –
Check the Preferred custom server IP checkbox, and key in the IP
address of the time server of your choice.
3. If you want to configure an alternate time server, check the Alternate
time server checkbox, and repeat step 2 for the alternate time server
entries.
4. Key in your choice for the number of days between synchronization
procedures.
Finishing Up
When you have finished making your settings on this page, click Save.
After you have saved your changes, if you want to synchronize immediately,
click Adjust Time Now.
