![Aten PE4104G [14/84] Optional accessories](/views2/1978081/page14/bge.png)
IP Control Box User Manual
4
Optional Accessories
Sensors
Sensors are optional accessories. You can use the IP Control Box unit without
sensors. However, if you want to have complete energy management of an
instrumented data center with the use of the IP Control Box, you would need
to use eco DC software and install sensor to generate a complete energy-
efficient data and chart. Higher sensor installation density is helpful to generate
more accurate data. A sensor-enabled installation is required to generate a more
complete energy-efficient data and chart. Higher sensor installation density is
helpful to generate more accurate data. Available sensors are show in the table,
below:
Sensor Management
Sensors can be managed via the IP Control Box’s built-in graphical user
interface (GUI) or with the eco DC software that can be the
ATEN website.
Cable Holders
Cable holders are optional accessories. For added safety, use ATEN Lok-U-
Plug cable holders to secure the cables from your attached devices in place on
the eco PDU unit. Use only the ATEN Lok-U-Plug cable holders that have
been specifically designed to work with the eco PDU. Using any other kind of
cable securing device could be highly dangerous. For more information, see
Securing the Cable, page 10.
Sensor Part Number
Temperature EA1140
Temperature / Humidity EA1240
Differential Pressure / Temperature EA1340
Part Number Description
2X-EA07 Lok-U-Plug Cable Holder (10 pcs)
2X-EA08 Lok-U-Plug Installation Tool (4 pcs)
2X-EA10 C14 EZ-Lok Plug Connector (10 pcs)
2X-EA13 C14 Smart-Lok Plug Connector (10 pcs)
