Aten PE4104G [36/84] When you have finished making your configuration settings click save

IP Control Box User Manual

When you have finished making your configuration settings, click Save.

Name From 1 to 16 characters are allowed depending on the

Account Policy settings. See Account Policy, page 39.

Password From 1 to 16 characters are allowed depending on the

Account Policy settings. See Account Policy, page 39.

Outlet This field allows you to set the outlet-by-outlet permissions of

the user. Click on the user/port icon to cycle through the three

permissions options, as follows:

User has complete access to this outlet.

User has read-only access to this outlet.

User has no access to this outlet.

Field Description
