IP Control Box User Manual
22
Remote Turn ON
Method
Use the drop-down menu to select one of the choices, below:
Wake on LAN
This is a Safe Shutdown and Restart option. If this is
selected, when an Outlet is turned Off, the eco PDU first
sends a message to the computer telling it to prepare for a
shutdown; it then waits for the amount time set in the Power
Off Delay field to give the OS time to close down before the
computer is powered down to standby mode.
Likewise, when the Outlet is turned On, the eco PDU waits
for the amount time set in the Power On Delay field, then
sends an Ethernet message to the computer connected to
the Outlet telling the computer to turn itself On.
Note: For Safe Shutdown and Restart, the computer must
be running Windows (98 or higher), or Linux, and the Safe
Shutdown program (available by download from our
website), must be installed and running on the computer.
System after AC Back
This is a Safe Shutdown and Restart option. If this is
selected, when an Outlet is turned Off, the eco PDU first
sends a message to the computer telling it to prepare for a
shutdown; it then waits for the amount time set in the Power
Off Delay field to give the OS time to close down before the
computer is powered down.
When the Outlet is turned On, the eco PDU waits for the
amount time set in the Power On Delay field, then sends
power to the server. When the server receives the power, it
turns itself on.
Note: For Safe Shutdown and Reboot, the computer must
be running Windows (98 or higher), or Linux, and the Safe
Shutdown program (available by download from our
website), must be installed and running on the computer.
Kill the Power
If this option is selected, the eco PDU waits for the amount
time set in the Power Off Delay field, and then turns the
Outlet's power Off. Turning the power off performs a cold
(non-safe) shutdown.
MAC Address In order to use either of the Safe Shutdown and Restart
methods the MAC address of the computer connected to the
outlet must be filled in here.
Control/Display Description
